The M12 PCB (Printed Circuit Board) connector is a type of circular connector designed to be mounted directly onto a circuit board. These connectors are commonly used in various industrial and electronic applications where a reliable and robust connection is required. The M12 PCB connectors are part of the broader M12 connector family but are specifically designed for integration into printed circuit boards.
Key features of M12 PCB Panel Mount connectors include:
1. Circular Design: Like other M12 connectors, M12 PCB connectors have a circular design with a threaded coupling mechanism. This design ensures a secure and reliable connection.
2. Panel Mounting:M12 PCB panel connector is mounted directly onto the surface of a printed circuit board, providing a compact and space-efficient solution for device connectivity. There are front panel mount and rear panel mounting installation methods.
3. Keying and Coding:M12 PCB mount connector often comes with various keying and coding options, such as A-coding, B-coding, D-coding, X-Coding, K-coding, L-coding, S-coding, T-coding etc. These designations help ensure that connectors are correctly matched and prevent mismating.
4. Pin Configurations:M12 connector PCB mount comes in different pin configurations, including 3, 4, 5, 8, and more pins. The number of pins depends on the specific application and the data or power requirements.
5. Application Diversity: M12 PCB connectors find applications in industrial automation, machinery, robotics, sensors, and other electronic systems where a reliable and compact connection is needed. They are commonly used in environments that may expose the connectors to moisture, dust, and other challenging conditions.
6. IP Ratings: M12 connectors often come with Ingress Protection (IP) ratings such as IP67, IP68, IP69K, indicating their resistance to dust and water. This makes them suitable for use in harsh industrial environments.
When integrating M12 PCB connectors into a design, it's crucial to consider the specific requirements of the application, such as the coding type, pin configuration, and environmental conditions. The connectors are available from various manufacturers, and compatibility is generally ensured through industry standards for M12 connectors.
FLECONN can provide high quality 180 degree straight 3 pin 4 pin 5 pole 6 positions 8 pin male and female a-code b-code c-code d-code l-code k-code s-code t-code x codem12 pcb panel mount connector with PG9 and m16x1.5 front and rear fastening thread.
